50-T Series Loads Technical Information

Specifications:

• Power Rating:
  • 50 W MAX. @ 40° C
  • 60 W MAX. @ 25° C
• Frequency Range & VSWR
  • DC to 1 GHz at 1.10:1 MAX.
  • 1 GHz to 4 GHz at 1.25:1 MAX.
• Impedance: 50 Ohms (nominal)
• Ambient Temperature Range: -40° C to +40° C
• Operating Position: ANY (convection cooled)
• Finish: Black Anodized Aluminum
• Nominal Size: 4.60" x 2.30" (for specifics, see images below or attached stp/step files)
• Weight: Approx. 1.1 LBS

***STP or STEP files are attached - see download link below. If accessing this through chat, please visit the Bird Product FAQs.

For the 50-T-FN:

For the 50-T-MN:

For the 50-T-FB:

For the 50-T-MB:
